How to Resolve Managed Metadata Madness in SharePoint?

Microsoft Flow that's used in this demo - it uses an Azure Function to extract text from a doc, which is then sent to Text Analysis, and finally written back to SharePoint. In the end, it sends notifications of the status of the run.

Using Azure Functions and Cognitive Services Text API to enrich a Flow that fills Metadata for new items in a Modern SharePoint Team Site. That’s, in a nutshell, the solution I submitted to a recent online hackathon. Quite a mouthful, isn’t it? The whole solution (and a public vote, if you’re interested!) is available here: https://devpost.com/software/resolving-managed-metadata-madness-in-sharepoint – this blog post will describe the solution and the reasoning behind it.

Preface

Some time ago my manager asked me to take a few weeks off, since I had accrued quite a lot of overtime during the hectic months working for Valo. I got bored quite quickly, so I was pretty happy to encounter an online hackathon organized by Devpost. I wasn’t aware of them beforehand, but they seemed to have hosted quite a few interesting hackathons before, so I thought I’d also take part into a hackathon they were just hosting: “Work smarter, not harder with Office 365.”

I’m not a huge fan of hackathons, but the topic was too good to miss, so I submitted a solution I’d been thinking about implementing, but didn’t have a good enough reason to implement it for customers.

Description of the issue

So, which issue am I aiming to solve? Let’s see…

  • The amount of data is surging (~90% of the data in the world has been created in the last 2 years)
    • To ensure that data in organizations is useful, you need to make sure, that your users find it easily!
  • A great “Enterprise-y” solution has been metadata tagging!
    • However, users generally hate doing that manually
    • Automatic solutions are either cumbersome to maintain, expensive to develop, or both
    • Many required metadata fields will cause users to migrate to shadow IT solutions (like DropBox) – or not use any collaboration solutions at all!
Resolving Managed Metadata Madness in SharePoint

Fig. 1: Resolving Managed Metadata Madness in SharePoint – in one Flow!

The Solution

Using Azure Functions and Cognitive Services Text API to enrich a Flow that fills Metadata for new items in a Modern SharePoint Team Site. Cool solution with fun new tools!

  • We’ll be using Modern Team Sites in SharePoint for document storage. That enables effortless collaboration in the cloud!
  • SharePoint’s Search is decent, but thorough metadata tagging makes it a lot more useful.
  • Using Azure Cognitive Services we can fill the metadata fields automatically – without any user interaction at all!
  • Users can find the content, and hence will be happy! 🙂

So essentially, what happens is, that this Flow automates metadata tagging for SharePoint Online. Like in the graph (Fig. 1), these are roughly the steps:

  1. User uploads a document
  2. This fires a Flow attached to Document Library
  3. The Flow will call the Azure Function that’ll do the heavy lifting
  4. An Azure Function will run, extract text, and analyze it using Azure Cognitive Services
  5. The Azure Function will then write the info back to SharePoint Online
  6. Finally, notifies admin of the execution and the creator of the file.

There’s a larger description and a demo video (in case the demo is not visible on the hackathon demo page, see it below! The actual demo starts around 3:10, it’s mainly issue and solution description before that) available on the hackathon website: https://devpost.com/software/resolving-managed-metadata-madness-in-sharepoint

Call to sites Graph API requires “owner” permissions for site collection regardless of app permissions

Okay – yet another weird issue, and a hacky workaround. I was developing an app that was calling a SharePoint site through Graph API, using jQuery $.ajax call (developed in TypeScript), and ran into surprising 401 errors. I did find a workaround, but am also working on an actual fix.

Description

To get SharePoint site ID, which is needed when accessing SharePoint lists, the calls seemed to fail for my test accounts. Everything was working fine for my developer account, which was a global admin, so the first thing I was suspecting was of course permissions…

The first offending test account was a Group member, and a restricted reader in the site collection I was trying to access via Graph. The account was also a contributor on the root site of the tenant. And all of my accounts were licensed with E3/E5.

I knew that this part of the code was supposed to get a site id for a certain SharePoint site collection with a call to Graph API, similar to this one:

https://graph.microsoft.com/v1.0/sites/<tenant>.sharepoint.com:/sites/<site>/

It worked for my developer account, but just wouldn’t work for the test accounts! This is the error I got: Continue reading

4 ways to fix error AADSTS65001 (The user or administrator has not consented to use the application)

Azure AD Login error

Fixing issues with Azure AD authentication for Enterprise applications can be tricky. This article contains multiple different fixes to an issue, where granting admin consent has somehow failed. Not all of the different solutions will work for all situations, though! That’s why I included a couple of different options to try… 🙂

Why do you even get issues with Admin Consent (like AADSTS65001)?

You’re trying to add or use an app, that requires such permissions from your tenant, that can only be granted by an administrator. Typically this app has to be added by a global administrator. If it’s an enterprise application, it could also be in an invalid state after someone tried adding the app without sufficient permissions.

Our investigation was focused on a mobile app, that’s deployed as an enterprise app. Most of the things should apply for web-based apps or console programs or whatever else you’re deploying, too.

The whole error might look something like this: Continue reading

Getting Connect-MsolService (and other SharePoint Online cmdlets) to work

Connect-MsolService

In this post, I’ll try to archive everything you need to download and install to get commandlets like Connect-MsolService working. I’ve had to do it a couple of times when changing laptops, so it’s good to document them somewhere 🙂

Required installations:

  1. Microsoft Online Services Sign-In Assistant for IT Professionals RTW
    1. https://www.microsoft.com/en-us/download/details.aspx?id=28177
  2. SharePoint Online Management Shell
    1. https://www.microsoft.com/en-us/download/details.aspx?id=35588
  3. Windows Azure Active Directory Module for Windows PowerShell (v1)
    1. http://connect.microsoft.com/site1164/Downloads/DownloadDetails.aspx?DownloadID=59185

Now, to run cmdlets like “Connect-MsolService”, just start SharePoint Online Management Shell (or PowerShell).

If you also need Azure Remote Management (AzureRM) cmdlets, run this in an elevated PowerShell:

Continue reading

Applying Entity Framework’s Code-First Migrations against a Database in Azure by running Update-Database

This post describes how to run Entity Framework’s code-first migrations against a database located in the Windows Azure. This is done by running Update-Database commandlet with suitable switches, see below.

The problem and symptoms

Okay, so you’re developing your MVC+EF cool web app with a database in Azure, and you’re using code-first migrations. Cool! What’s nice with code-first-migrations is the fact they are run automatically even in the cloud the next time your app is running (as long as you publish your app with that little box ticked – something like in the screen capture below). But wait – what if there are conflicts – what kind of errors are you going to get?



Azure Web Publish

Azure Web Publish

Not very useful ones, I’m afraid, and it’s a pain navigating the Azure portal to fetch the log files. At some point – for me, it wasn’t the first time I ran the web app, but the phase when I was logging in – you’ll be getting the error the migrator internally throws. That might be enough to point you to the right direction, and maybe you’ll be able to figure out what’s wrong! But if that’s not the case, here’s the way to run Update-Database against your Azure Database!

Continue reading

Fixing “An error occurred while updating the entries” while running code-first migrations in MVC 5 app

Update-Database error

This post describes an issue with EF’s code-first migrations, when mapping between DB’s DateTime and C#’s DateTime kind of fails, and results in Update-Database cmdlet failing.

Symptoms

While running Update-Database in a code-first ASP.NET MVC5 + EF6 -project, you get a following (or similar) error:

Continue reading

Fixing error “Cannot open server – – requested by the login. Client with IP address – – is not allowed to access the server.” in Azure deployments from Visual Studio

Azure SQL Error

This post describes how to work your way around the exception ‘Cannot open server – requested by login…’ The issue is caused by Azure’s somewhat annoying firewall logic, and might stop you from accessing your databases from your development machine.

Symptoms

When trying to publish a web project to Azure from Visual Studio, you suddenly get the following (or similar) error message:

Cannot open server ‘xxx.xxx.xxx.xxx’ requested by the login. Client with IP address ‘xxx.xxx.xxx.xxx’ is not allowed to access the server. To enable access, use the SQL Azure Portal or run sp_set_firewall_rule on the master database to create a firewall rule for this IP address or address range. It may take up to five minutes for this change to take effect.”

Reason

Your IP address has changed (for any reason) and Azure won’t allow your login anymore (as there’s a built-in IP filtering enabled). Azure kind of works as expected, Visual Studio’s error message just isn’t the most useful out there. Luckily, instead of running stored procedures or navigating the constantly evolving Azure Portal to desperately try to find a place where to edit SQL Server firewall rules, you can do this directly and conveniently in Visual Studio.

Solutions

Update 13.7.2016:

It appears that the pop-up dialog mentioned below sometimes randomly does not appear. In that case, there’s another way to add the firewall rule, see here.

Solution 1

You’ll need to connect to the SQL Server through Visual Studio, which will prompt you to allow access to the server for your current IP address. Like so:

Continue reading

The specified path, file name, or both are too long. The fully qualified file name must be less than 260 characters, and the directory name must be less than 248 characters.

Too long deployment path

This post describes a few different ways of fixing the error “The specified path, file name, or both are too long. The fully qualified file name must be less than 260 characters, and the directory name must be less than 248 characters.” one can get when trying to package/publish a SharePoint solution, web site or Azure Webjob.

UPDATE 11.4.2016: I actually got this nasty exception on another occasion (Azure webjob publish), so I updated the text accordingly.

Symptoms

Visual Studio throws the following error when packaging a SharePoint solution to a .wsp file, OR when deploying or publishing your web project (for example Azure Webjob).
